Bulky Waste Resource Processing System

Well-Advanced bulky waste resource processing system is mainly composed of crushing equipment, sorting equipment and baling equipment. The end product size after crushing can reach 50mm. Metals, wood and sponges are sorted and recycled to achieve effective resource utilization.

Solution Profile

Capacity: 3-15 tons/h
Applications: Furniture, mattress, waste sofas, wooden cases, tree trunks (Diameter 30-100mm, length less than 1 meter), etc.
Well Solution:
The bulky waste is collected and transported to the bulky waste crushing treatment center.The large waste is transported by the chain conveyor to the preliminary crusher and broken into smaller specifications.Iron wire, iron sheet and other metals are sorted with iron remover, and other materials are transported to the fine crusher by belt conveyor for further crushing.After crushing, the discharge material is further separated from the iron component through the magnetic separator, and other crushing materials are transported to the air separator through the belt conveyor, which is further screened according to the weight of the material, light materials such as sponge leather are transported to the baler, and the whole line system is sealed and dust-removed.

Bulky Waste Recycling Solution

Applications

Sofa | Mattress
Wooden Cabinets Wooden Doors |
 Board Waste | etc
Other Bulk Waste

End Product

Metals
Wood | Plastic | etc
Textile | Sponge  etc

Flow Chart

Video

Project Case
